Test Center
- From: www.glida.cn Add time: 2012-09-24 10:01:54 Click: 44
The battery safety performance test deviceMainly for various materials and surface treatment, including paint, electroplating, inorganic and organic coating film, anodic treatment, rust-proof oil corrosion prevention treatment, testing its products on the corrosion resistance of
1> has an automatic / manual water system, water shortage can automatically supplement water function, test without interruption;
2> temperature controller using a digital display, PID control error of ± 1℃;
3> double over-temperature protection, water level warning to ensure safe use;
4> test chamber adopts direct steam heating method, heating speed and uniformity, reduce the standby time;
5> precision glass nozzle adjustable fog, fog amount. Spray tower of conical diffuser uniformly fog diffusion, and naturally fell on the card, and to ensure no crystalline salt occlusion;
6> saturated air barrels by Henry`s law, to be heated and humidified, and provide the required humidity test chamber. ( can automatically adjust the test chamber humidity ).
Programmable touch screen type constant temperature and humidity test chamber
Model: GX-3000-80L
Temperature range: -40℃ - +150℃and humidity range: 20 - 98%R.H.
Used for testing battery performance at high temperature and low temperature, constant temperature and humidity performance and relative humidity testing
Battery low altitude simulation test box model: GX-3020-Z
Used for testing the simulation cell in aerial transport may occur in low pressure environment ( 11.6kPa ) storage state
Sub-capacity cabinet -- 5V/3A for battery capacity at discharge. The cycle life of high and low temperature discharge test
Battery test
Used for testing the resistance of voltage
Protection board tester model: MPT04S030 for multi-section protection board performance test
Electronic load used in discharge performance test
The battery safety performance test device for detecting simulation of various types of batteries, by acupuncture, extrusion, impact, combustion,
Thermal shock, short circuit, over charge, forced discharge when the situation, in order to evaluate the service life of the battery and performance, part of the experimental equipment is as follows:
1> high temperature short circuit test box:
Simulation environment of high temperature, high temperature short circuit test battery safety performance, has the automatic function of heat preservation, can also be used for normal temperature, thermal shock test of short circuit.
2> battery thermal shock experiment box:
Simulation of rapid warming environment outside, with temperature programmed function, convenient operation, at a heating rate within the stipulated time to reach test temperature, and maintain a certain time. Using hot air circulation system, ensure working uniform temperature distribution. With over-temperature protection function and timing shutdown function.
3> battery incineration furnace:
For the test battery in from outside sources of ignition safety performance. Automatic ignition, test process automatic control, can the whole video.
4> impact test device:
Simulation of batteries or battery by the heavy impact when the situation. Remote control, safe and reliable. Can the whole video.
5> squeeze testing machine:
Simulation of batteries or battery by the external extrusion case. The battery in two plane is extruded through a hydraulic arm, Shijiayue 13KN extrusion, extrusion to hydraulic device of the pressure gauge reading reached 2500 ( 17.2Mpa ), once the maximum pressure, lifting the extrusion. Extrusion pressure, time, unit of measurement can be adjusted freely, reliable performance. Can the whole video.
6> acupuncture test machine:
Simulation of batteries or battery internal short circuit condition. Acupuncture, acupuncture time speed, pressure adjustable, fixture for fixing the battery, can the whole video, security facilities.
7> drop test machine:
The apparatus specimen maximum weight is 2.0kg, drop height 300-500mm ( adjustable ), stainless steel ruler, pressure adsorption type clamping way, support multiple parts, much angle (edge, angle, surface ) drop method. Suitable for battery, mobile telephone, electronic dictionary and other small consumer electronics products and components of free fall test, can meet the GB8897.4-2002, IDT IEC60086-4:2000 test method of demand.
Salt spray test machine model: GX-3040
